Wns Factory Automatic Diesel Waste Oil Fired Steam Boiler Price

Wns Factory Automatic Diesel Waste Oil Fired Steam Boiler Price

Product Details:

Place of Origin: HENAN ,CHINA
Brand Name: TAIGUO
Certification: CE\EAC\SGS\ISO19001\ISO24001\ISO45001
Model Number: WNS

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: USD4500-25500 Set
Packaging Details: Full Container
Delivery Time: Deliver the goods at the agreed time
Payment Terms: TT, L/C, D/A, D/P
Supply Ability: 1000
Get Best Price Contact Now

Detail Information

Weight: 6.8t-62t Installation Mode: Skid Mounting
Working Pressure: 1.0、1.25、1.6Mpa Fuel Type: Natural Gas, Light Oil, Heavy Oil, Liquefied Petroleum Gas
Thermal Efficiency: 96% Mode Of Transport: Land, Air, Sea
Steam Temperature: 184、194、204 Dimension: LCD Display English And Chinese Menu Can Touch Screen
Drum Placement: Horizontal Boiler Usage: Industrial, Home, Vehicle, Power Station
Origin: Henan

Product Description

Product Description:

TAIGUO WNS series oil/gas boiler is a kind of automatic horizontal internal combustion three return wet back type oil (gas) quick loading boiler, combustion chamber large volume design, make the combustion more full; The pipe adopts thread structure to enhance the heat transfer effect. Boiler equipped with international first-class brand burner and valve group and perfect automatic control device and safety protection device, to achieve automatic water level control and dangerous low water level alarm, stop the furnace; Automatic steam pressure control and overpressure alarm; Boiler automatic ignition, burner fire automatic regulation and flameout protection, to ensure the safe operation of the boiler. Usually suitable for 500kg to 20t/h capacity.


  • It has the three returns design, so exhausted smoke temperature is low;
  • Adopted the latest technology, it is designed with a combustion chamber with large volume.It is equipped with a world-known burner,making the combustion more sufficient and ensuring higher efficiency and lower failure rate.
  • It adopts advanced corrugated furnace pipe structure,increasing the heat surface area, and satisfying free expansion of the furnace pipe after heating.
  • It adopts wet back structure with high reliability and low maintenance cost.The wet type flue gas flow and compact structure to prevent the tube plate cracking,Science and calculate the heated area, output assured;

Technical Parameters:

Parameter Value
Boiler Type Steam Boiler
Thermal efficiency 96%
Dimension LCD Display English and Chinese Menu Can Touch Screen
Fuel Type Natural Gas, Light Oil, Heavy Oil, Liquefied Petroleum Gas
Evaporation capacity 0.5t/h-30t/h
Mode of transport Land, Air, Sea
Weight 6.8t-62t
Quality guarantee 1 Year
Electrical element PLC
Structural form Horizontal
Oil-Burning Heating Boiler Yes
Gas Fired Boiler Yes
Oil Burning Boiler Yes


Applications: textile factory, food and beverage, chemical industry, light industry, rubber, printing and dyeing factory, paper factory, wood process-ing, clothing,laundry, etc.

Packing and Shipping:

Gas Oil Boiler Packaging and Shipping:

The gas oil boiler will be packaged in a cardboard box or wooden crate for extra protection during shipping. The size and weight of the gas oil boiler will depend on the size and capacity of the boiler.

The gas oil boiler will be shipped via a truck, depending on the size and weight of the boiler.

The gas oil boiler is shipped with all the necessary installation instructions and manuals.



1. How to buy a good boiler?

a. Choose a good supplier, A grade boiler manufacturer.
b. Specification is clear, steam or hot water, capacity,fuel,pressure and so on
c. Price is not the only problem, quality and service also important.

2. What is your main product?

Steam boiler, hot water boiler, thermal oil boiler and pressure autoclave.
Gas fired boiler, oil fired boiler, diesel fired boiler, coal fired boiler, biomass fired boiler.
Industry boiler, paper machine boiler, sugar mill boiler, printing industry boiler, food industry boiler,
power plant boiler,textile mill boiler, garment industry boiler and so on.

3. Why choose us?

a. A grade boiler factory, long history since 1976.
b. Henan boiler industrial area, Taikang No.1 boiler factory
c. China famous brand, ISO certificate
