Small Electromagnetic Electric Heating Steam Boiler Covers An Area Of Small Thermal Efficiency

Small Electromagnetic Electric Heating Steam Boiler Covers An Area Of Small Thermal Efficiency

Product Details:

Place of Origin: Henan, China
Brand Name: TAIGUO
Certification: CE、EAC、SGS
Model Number: LDC

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: US $5000.00-10000.00
Packaging Details: Bulk, packaged
Delivery Time: 10-30working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100set
Get Best Price Contact Now

Detail Information

Product Name: Electromagnetic Electric Heating Steam Boiler Rated Power: 160-1600KW
Rated Current: 240-2400A Voltage Frequency: 380/50V/HZ
High Light:

small heating steam boiler

,

thermal efficiency heating steam boiler

,

covers an area heating steam boiler

Product Description

Product introduction:

Electromagnetic steam generator is a new type of steam equipment, which uses the principle of electromagnetic induction to convert electrical energy into heat energy, so as to produce steam. The electromagnetic steam generator uses electromagnetic induction heating technology, which can heat water to a very high temperature in a short time with higher efficiency, and can convert electrical energy into heat energy with an efficiency of more than 98%. More environmentally friendly, no combustion process, will not produce harmful gases and smoke. Finally, it is more energy saving, and can automatically adjust the output power according to actual needs, and effectively use energy. This kind of steam generator has the advantages of high efficiency, environmental protection and energy saving, and has been widely used in industry, medical treatment, catering and other fields.

Product advantage:

1, one-click start:
The electromagnetic steam generator adopts PLC control system, touch screen interface, fingertip touch, easy to operate, remote control, greatly saving labor costs.

2, low pressure high temperature steam:
The steam system can easily adjust the pressure and temperature, and can produce superheated steam up to 500℃ under very low pressure conditions, which is used for food drying or dehydration, oil-free cooking, potato peeling at high temperature, wood drying, online maintenance of environmental protection building materials, high temperature and low pressure synthesis of polymer materials and other occasions.

3, high security:
The water and electricity separation of the heating core part of the equipment will not occur the leakage problem of the traditional electric heating tube. The electric heating tube of the conventional electromagnetic steam generator is immersed in water for a long time, which is easy to cause leakage accidents, endangering personal safety, coal burning or other steam equipment heated by open fire, easy to explode, and the accident rate is high.

4, ultra-high stability:
The unique structure and heating method of the steam system and the multiple safety protection design ensure the ultra-stable operation of the equipment, and the product life can reach more than 10 years.

Technical parameter:

Type specification LDC-160 LDC-240 LDC-320 LDC-400 LDC-640 LDC-800 LDC-1280 LDC-1600
Rated power(KW) 160 240 320 400 640 800 1280 1600
Rated current(A) 240 360 480 600 960 1200 1920 2400
Voltage frequency(V/Hz) 380/50
Electrothermal efficiency(%) ≥98
Class of protection(IP) 50
Working pressure(Mpa) 0.01-1.0
Evaporation capacity(t/h) 224 336 448 540 896 1120 1792 2240
Air outlet/sewage outlet(DN) 25/40 25/40 40/40 40/40 50/40 50/40 65/40 80/40
Auxiliary control function Automatic + remote
Product weight(kg) 640 960 1200 1350 2560 3500 5120 6400
Apparent dimension(m) 1.8*1.6*1.7 2.0*1.6*1.7 2.2*1.6*1.7 2.6*1.6*1.7 4.4*1.6*1.7 4.5*1.6*1.7 5.0*1.6*1.7 5.5*1.6*1.7
