Horizontal Electric Heating Electromagnetic Steam Generator Energy Saving And Environmental Protection Can Be Customized

Horizontal Electric Heating Electromagnetic Steam Generator Energy Saving And Environmental Protection Can Be Customized

Product Details:

Place of Origin: Henan, China
Brand Name: TAIGUO
Certification: CE、EAC、SGS
Model Number: LDC

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: US $5000.00-10000.00
Packaging Details: Bulk, packaged
Delivery Time: 10-30 working days
Payment Terms: L/C, T/T, Western Union
Supply Ability: 100set
Get Best Price Contact Now

Detail Information

Product Name: Horizontal Electromagnetic Steam Generator Rated Power: 160-1600KW
Rated Current: 240-2400A Voltage Frequency: 380/50V/HZ
High Light:

energy saving Horizontal electromagnetic steam generator

,

electric heating Horizontal electromagnetic steam generator

,

environmental protection Horizontal electromagnetic steam generator

Product Description

Product overview:

Electromagnetic steam generator is a new type of steam equipment, which uses the principle of electromagnetic induction to convert electrical energy into heat energy, so as to produce steam. This kind of steam generator has the advantages of high efficiency, environmental protection and energy saving, and has been widely used in industry, medical treatment, catering and other fields. The working principle of the electromagnetic steam generator is based on the principle of electromagnetic induction. When alternating current passes through the electromagnetic coil, a magnetic field will be generated around the coil, and the change in the magnetic field will trigger a change in the current inside the conductor, which will generate heat. In this process, electrical energy is converted into heat, which in turn produces steam.

Product advantage:

1, high thermal efficiency:

According to the test of the authoritative department, the thermal efficiency of AIX electromagnetic steam generation system is 98.3%, and the comprehensive use cost is far lower than that of traditional heating.

2, the steam speed is fast:

Compared with the traditional electric heating tube, it has an unparalleled heating speed, and can produce steam in 60 seconds, saving time and worrying.

3, absolutely no emission pollution:

Compared to conventional steam boilers, electromagnetic heating produces no emissions.

4, modular installation:

The equipment can be used single, can also be conveniently used in parallel, centralized steam supply, that is, ready to use, save space and construction costs, can also be conveniently disassembled and used independently according to needs.

Technical parameter:

Type specification LDC-160 LDC-240 LDC-320 LDC-400 LDC-640 LDC-800 LDC-1280 LDC-1600
Rated power(KW) 160 240 320 400 640 800 1280 1600
Rated current(A) 240 360 480 600 960 1200 1920 2400
Voltage frequency(V/Hz) 380/50
Electrothermal efficiency(%) ≥98
Class of protection(IP) 50
Working pressure(Mpa) 0.01-1.0
Evaporation capacity(t/h) 224 336 448 540 896 1120 1792 2240
Air outlet/sewage outlet(DN) 25/40 25/40 40/40 40/40 50/40 50/40 65/40 80/40
Auxiliary control function Automatic + remote
Product weight(kg) 640 960 1200 1350 2560 3500 5120 6400
Apparent dimension(m) 1.8*1.6*1.7 2.0*1.6*1.7 2.2*1.6*1.7 2.6*1.6*1.7 4.4*1.6*1.7 4.5*1.6*1.7 5.0*1.6*1.7 5.5*1.6*1.7



Horizontal Electric Heating Electromagnetic Steam Generator Energy Saving And Environmental Protection Can Be Customized 0Horizontal Electric Heating Electromagnetic Steam Generator Energy Saving And Environmental Protection Can Be Customized 1

Q1: How can you get the best price quickly?
1.We need to know the boiler capacity, the fuel you plan to use and the steam pressure you need, and then we can confirm the boiler model.
2. Customer needs to provide us your name, email address and company name, and then we will send you price list immediately.And if you use whatsapp, skype or wechat, you can provide us your ID, it will be more convenient for our communication.

Q2:Why choose us?
1.40+ years of boiler manufacturing experience, 10 years of export experience.A grade boiler factory.
2.Free replacement of parts for one year, lifetime maintenance of the main engine, except for improper operation.

Q3: Details of electric control cabinet
Electric control cabinet adopts PLC touch screen, display in English. It shows working condition details of boiler, such as water temperature, water pressure, exhaust gas temperature, and over-pressure alarm, etc. In addition, the cabinet is used for set up the parameter, record and analyze the operation data, etc.
Q4:What is the using life of your boiler?
1.Normally the boiler is designed for 20 years life span, but with right operation and good maintenance,the boiler can be used for 20-25 years.
