Electric Heating High Temperature Steam Boiler Paper Industry High Efficiency

Electric Heating High Temperature Steam Boiler Paper Industry High Efficiency

Product Details:

Place of Origin: Henan, China
Brand Name: TAIGUO
Certification: CE、EAC、SGS
Model Number: DZZQ

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: US $7000.00
Packaging Details: Bulk, packaged
Delivery Time: 30 working days
Payment Terms: L/C, T/T
Supply Ability: 100set
Get Best Price Contact Now

Detail Information

Product Name: Electric Heating High Temperature Steam Boiler Voltage Frequency (V/HZ): 380/50
Electric Heating Efficiency (%): ≥95 Auxiliary Control Function: Automatic Control + Remote Control
High Light:

Electric Heating High Temperature Steam Boiler

,

Paper Industry High Temperature Steam Boiler

Product Description

Electric Heating High Temperature Steam Boiler Paper Industry High Efficiency

Product name:

Electric heating steam generator, which is powered by electricity and converts water into steam, brings endless convenience to our life production. Its working principle is simple and efficient, and the electric energy is converted into heat energy through the electric heating element so that the water quickly reaches the boiling point and generates steam. The application of this device is wide, from the home to the factory, from the hospital to the hotel, almost everywhere. It has the advantages of small footprint, simple automatic operation, energy saving and environmental protection, low running noise, no scaling and no corrosion.

Product advantage:

1. Ultra-high thermal efficiency
using frequency conversion heating technology, thermal efficiency up to 95%
2. Intelligent remote control
constant temperature automatic control and mobile phone remote control, more simple operation
3 . Energy saving and environmental protection
saving boiler production electricity cost environmental protection standards


Technical parameter:

Model speci fications DZZQ-36 DZZQ-72 DZZQ-144 DZZQ-216 DZZQ-360 DZZQ-504 DZZQ-720 DZZQ-1080 DZZQ-1400
Rated power (kW) 36 72 144 216 360 504 720 1080 1400
Rated current (A) 54 108 216 324 540 756 1080 1620 2160
Voltage frequency (V/HZ)



380/50



380/50



380/50



380/50



380/50



380/50



380/50



380/50



380/50

Electric heating efficiency (%)



≥95



≥95



≥95



≥95



≥95



≥95



≥95



≥95



≥95

Number of heating tube groups (group))



2



2



4



6



10



14



20



30



40

Working pressure (Mpa)



0.1-1.0



0.1-1.0



0.1-1.0



0.1-1.0



0.1-1.0



0.1-1.0



0.1-1.0



0.1-1.0



0.1-1.0

Evaporation (kg/h)



50



100



200



300



500



700



1000



1500



2000

Air outlet/

sewage outlet (DN)



25/40



25/40



25/40



25/40



40/40



50/50



50/50



65/50



65/50

Auxiliary control function Automatic control + remote control
Product weight (kg)



85



150



318



450



750



1000



1300



2100



2600

Appearance size (m) 0.8*1.0*1.6 0.8*1.0*1.7 1.4*1.4*1.7 2.0*1.6*1.7 1.4*1.4*1.7 1.6*1.6*1.7 2.6*1.6*1.7 3.7*1.6*1.8 4.5*1.6*1.8


Electric Heating High Temperature Steam Boiler Paper Industry High Efficiency 0Electric Heating High Temperature Steam Boiler Paper Industry High Efficiency 1
Q1: How can you get the best price quickly?
1.We need to know the boiler capacity, the fuel you plan to use and the steam pressure you need, and then we can confirm the boiler model.
2. Customer needs to provide us your name, email address and company name, and then we will send you price list immediately.And if you use whatsapp, skype or wechat, you can provide us your ID, it will be more convenient for our communication.
Q2:Why choose us?
1.40+ years of boiler manufacturing experience, 10 years of export experience.A grade boiler factory.
2.Free replacement of parts for one year, lifetime maintenance of the main engine, except for improper operation.
Q3: Details of electric control cabinet
Electric control cabinet adopts PLC touch screen, display in English. It shows working condition details of boiler, such as water temperature, water pressure, exhaust gas temperature, and over-pressure alarm, etc. In addition, the cabinet is used for set up the parameter, record and analyze the operation data, etc.
Q4:What is the using life of your boiler?
1.Normally the boiler is designed for 20 years life span, but with right operation and good maintenance,the boiler can be used for 20-25 years.
