LCD Control Vertical Steam Boiler Internal Combustion Three Pass Durable

LCD Control Vertical Steam Boiler Internal Combustion Three Pass Durable

Product Details:

Place of Origin: Henan, China
Brand Name: TAIGUO
Certification: CE、EAC、SGS
Model Number: LHS

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: US $5000.00
Packaging Details: Bulk, packaged
Delivery Time: 30 working days
Payment Terms: L/C, T/T
Supply Ability: 100set
Get Best Price Contact Now

Detail Information

Product Name: Vertical Steam Boiler Fuel: Natural Gas, Light Oil, Liquefied Petroleum Gas
Steam Yield: 0.1t/h-1t/h Working Pressure: 0.4-0.7MPA
Steam Temperature: 151-170℃
High Light:

LCD control vertical steam boiler

,

three pass vertical steam boiler

,

LCD control vertical model steam boilers

Product Description

Product introduction:

Vertical steam boiler adopts automatic microcomputer control system, automatic control of equipment operation, no manual guard, automatic water intake system. Automatic pressure control system, automatic feeding system. With a low water level alarm and stop operation, overpressure alarm to stop the whole system, lower than the set pressure automatically start operation, reach the required maximum pressure automatically stop operation, using multiple safety design, safe and reliable. Factory configuration is complete, durable, safe and convenient. Fire tube arrangement structure, heating surface is large, temperature rise and steam production is fast. After combustion, the flue gas return cycle, the flue gas heat exchange is full, the exhaust smoke temperature is low, the water supply two stages of heat exchange, efficient energy saving and environmental protection. The whole factory, fast installation, simple operation, easy maintenance, safe, stable and reliable operation cost is lower than the generator produced by the general manufacturer

Product characteristics:

1. Complete combustion waste heat recovery high thermal efficiency
Equipped with flue gas waste heat recovery energy saver. The generator water supply absorbs the heat of the exhaust gas through the energy saving device of flue gas waste heat recovery. The temperature of water entering the furnace increases greatly. Improve the thermal efficiency of the generator to meet the national standard of energy saving and high efficiency.
2. One-click operation is safe and convenient
Configuration of microcomputer LCD control system, one-click operation, the water and electricity installation in place, set the automatic stop of high pressure and automatic start of the operation of low pressure, press the switch key, the generator will enter the automatic operation state, safe and simple, no professional furnace personnel, reduce the labor intensity of personnel.
3. Multi-protection security guarantee
The product is equipped with high quality pressure controller, safety valve, and multiple protection such as overpressure alarm, low water level alarm and overheating protection to ensure product quality and safety.
4. Strictly test industry standards
The steam production capacity and steam saturation have been strictly tested, and both meet the requirements of national and industry standards.
5. Machine factory save costs.
The modular machine is delivered with a water pump. Solenoid valve and check valve, only need to connect the power supply, steam pipe, water inlet pipe and sewage pipe can save the installation cost and a lot of installation materials.

Technical parameter:





Model



Rated

Capacity

(t/h)



Rated

Pressure

(Mpa)



Rated

Temperature

(C)



Maximum

transport weight

of boiler(t)





Maximum transport size of boiler( mm)

Fuel Consumption



diesel oil (Kg/h)



Natural

gas (m³/h)



LPG (kg/h)

LHS0.05 0.05



0.4



151

0.37 700× 650×1700 8.2 10.2 6.45
LHS0.1 0.1 0.59 800×750 ×2000 11.3 13.6 13
LHS0.2 0.2







0.4~0.7







151~170

0.68 900× 850×2000 15.6 18.7 19.4
LHS0.3 0.3 0.83 1000×950×2000 22.5 26.8 25.6



LHS0.5



0.5



1.07



1100×1050×2000



32.5



36.8



32



LHS0.7



0.7











0.4~0.7











151~170



1.45



1200×1150×2200



40.6



48.5



50



LHS1



1



1.78



1300×1250×2450



45.9



65.3



65



LHS1.5

1.5



1.9



1780×1600×3200



78.4



102.1



97



LHS2



2



5.2



2000×2000×4000



91.8



130.6



130



Note: 1,Fuel type:Light diesel oil/Heavy oil/Natural gas/Liquefied gas/City gas

2 ,Parameter is for reference only, we can design the boilers based on customers’ needs.



Company introduction:

Henan Taipan Boiler Manufacturing Co., LTD. (formerly "Henan Taikang Boiler Factory") was founded in 1976, is the birthplace of Henan Taikang boiler and leading enterprises. The company has strong scientific and technological force and advanced machinery and equipment, product quality is excellent; And has the production, installation and undertake the corresponding engineering technology design of rich experience. It has the national A-class boiler manufacturing license and the national 1-class boiler installation, transformation and maintenance license, and is A "contract-honoring and credit-keeping" enterprise in Henan Province. Factory area of more than 80,000 square meters, construction area of 18,000 square meters, the main boiler production equipment 350 sets (sets), advanced detection methods and perfect, with the annual production capacity of 12,000 tons of boiler. Technology first, market-based, and strive to develop and produce more reasonable and satisfactory products for the majority of users, is our unswerving pursuit. The main products of the company are automatic oil (gas) boilers and circulating fluidized bed boilers. Superior product quality and performance, leading the domestic level, won the Henan Province famous trademark and national, ministry, provincial "high quality, energy saving products" gold medal.

Product display:
